Ground Thawing Blanket 3000 x 1000mm

The Ground Thawing Blanket 3000 x 1000mm is a heavy-duty electric heating blanket designed to thaw frozen ground, soil and pipes while providing reliable freeze protection for construction materials, pipelines and equipment. Built from durable, weatherproof materials, it is the ideal solution for construction sites, civil engineering projects, utilities, landscaping and agricultural applications where cold weather can cause costly delays.

The blanket delivers controlled heat directly downwards through its insulated upper surface, allowing frozen ground to thaw quickly and efficiently while minimising heat loss. Under normal ground conditions, it can thaw up to 300mm of frozen soil within 24 hours, or up to 600mm in sandy ground, helping excavation and construction work continue safely throughout the winter months.

In addition to ground thawing, the blanket is widely used as a concrete curing blanket, providing consistent heat to improve curing times and protect freshly laid concrete, brickwork, masonry walls, bridge decks, precast components and decorative concrete from frost damage.

Manufactured from robust waterproof PVC, the blanket is designed to withstand harsh outdoor environments and repeated daily use. An integrated 70°C bi-metal thermostat automatically regulates the operating temperature, while the IP67-rated construction offers excellent protection against dust and water ingress.

Simple to install, the blanket is supplied with either a 2 metre Schuko power lead or a 2 metre industrial connector. Simply roll out the blanket over the required area, connect the power supply and allow the blanket to safely thaw or protect the surface. Once the task is complete, it can be quickly rolled up for transport and storage.

Whether you're thawing frozen ground before excavation, protecting valuable equipment or accelerating concrete curing, the Ground Thawing Blanket offers a dependable, energy-efficient solution that helps reduce downtime, improve productivity and keep projects moving during cold weather.

Features & Benefits

• Heavy-duty electric blanket for thawing frozen ground and soil

• Thaws frozen ground to approximately 300mm within 24 hours under normal conditions

• Can thaw up to 600mm in sandy soil

• Provides effective frost protection for pipes, pipelines and equipment

• Ideal for melting snow and ice on construction sites

• Suitable for concrete curing and temperature maintenance applications

• Top-insulated design directs heat downwards for maximum efficiency

• Durable waterproof and weatherproof PVC construction

• Built-in 70°C automatic bi-metal thermostat

• Easy to install, roll up and transport

• IP67 rated for demanding outdoor environments

• Custom sizes available on request


Technical Specifications

• Blanket Size: 3000 x 1000mm

• Operating Temperature: Fixed 70°C

• Outer Material: Heavy-duty PVC

• Protection Rating: IP67

• Power Cable: 2 metre cable

• Connection Options: Schuko plug or industrial connector

• Heat Direction: Downward-facing insulated design

• Custom Sizes: Available on request


Typical Applications

• Thawing frozen ground and soil

• Excavation and groundwork preparation

• Concrete curing

• Brickwork and masonry curing

• Bridge deck curing

• Precast concrete production

• Preheating construction materials

• Protecting construction materials from freezing

• Melting snow and ice

• Freeze protection for pipelines and pipework

• Heat maintenance for electrical and telecommunications cables


Suitable Industries

• Construction and civil engineering

• Agriculture

• Landscaping and groundworks

• Railway maintenance

• Utility contractors

• Plumbing and drainage

• Oil and gas

• Concrete and precast manufacturing

• Infrastructure maintenance

The Ground Thawing Blanket 3000 x 1000mm provides a safe, reliable and cost-effective solution for cold weather construction and maintenance. Designed to maximise productivity during freezing conditions, it helps prevent costly project delays by keeping the ground, materials and equipment at the optimum working temperature.

Sizes:

Custom sizes also available please get in contact with further details.

Lead Time: 1-2 weeks.

Please get in contact if you're needing more than 2+ products for further discount and a more competitive quotation.
